Power supply 12 V/DC 4,2 A installation box for key switch cono512000
Power supply unit 12 V/DC / 4.5 A, in installation box, surface-mounted
For supplying power to a maximum of 20 electronic showers, CONGENIAL FIT or CONBASE wall-mounted washbasin mixers, CONGENIAL and CONFLUSH washbasin manifolds. Wall-mounted distributor for wall installation, wired ready for connection, connection via pre-assembled 2 m connection cable with Schuko plug. Including pre-installation for the use of a key switch for thermal disinfection or external hygiene flushing.
The electrical wiring may only be carried out by a qualified electrician in accordance with DIN VDE 105-100.
Technical data
Operating voltage: 230 V / AC
Output voltage: 12 V ± 1% DC
Output current: 0 – 4,5 A
Output power: 54 W
Protection class: II
IP protection: IP65
Dimensions (WxHxD): 125x200x122 mm
