Power supply 12 V/DC 4,5 A hat rail monting cono511000
Power supply unit 12 V/DC / 4.5 A, for DIN rail mounting
For supplying power to a maximum of 20 electronic showers, CONGENIAL FIT or CONBASE washplace wall-mounted taps, CONGENIAL and CONFLUSH washplace manifolds, for installation in sub-distribution boards.
The electrical wiring may only be carried out by a qualified electrician in accordance with DIN VDE 105-100.
Technical data
Operating voltage: 230 V / AC
Output voltage: 12 V ± 1% DC
Output current: 0 – 4,5 A
Output power: 54 W
Protection class: II
Dimensions (WxHxD): 80x72x56 mm
