iQ lavatory faucet A10, chrome, IR-sensor, Click-plus, battery, without drain assembly, temp. mixing, G3/8 100.100.11
iQ lavatory faucet A10, with IR sensor, with temperature-mixing, chromed
Touchless, electronically controlled lavatory faucet:
• For connection to hot and cold water
• Modular single-piece design without separate installation box, sturdy metal housing, chromed
• Reliable solenoid valve ROBUST (minimal level of water pressure surge) and economic aerator
• Dual infrared sensors (with automatic setting feature), microprocessor
• Hot and cold water supply connection with flexible high-pressure hoses
• Follow-up time and sensor sensitivity adjustable with function key
• Check valves and built-in filters
• Temporary-off (cleaning) and continuous water flow time (filling of basin) activated by Click-plus
• Continuous water flow time and hygienic flush time adjustable with function key
• Temperature adjustable or fixable (vandal-resistant construction)
• Adjustable hot water limitation (mechanically)
• 12, 24 or 48-hour hygienic flush activatable with function key
• Compatible with CNX and Service APP: Control of stored operational data, settings and control functions
• Compatible with Service APP: Control of stored operational data, settings and control functions
Notice:
When integrated into the CNX Water Management System, the CNX Converter 6 V must be ordered separately.
When using the Service APP, the BLE Converter must be ordered separately.
Only possible with mains and VARIOconnect versions.
Battery: 6 V Lithium 2 CR5 - commercial; life time up to 4 years
Operating pressure: 0,3 – 10 bar
Water temperature (max.): 80 °C
Flow rate (approx.): 6 l/min / 1,6 gpm (3 bar)
Follow-up time: 1 s pre-set (adjustable with function key 0-10 s)
Continuous water flow and hygienic flush time: 2 min pre-set (adjustable with function key 0,5-20 min)
Temporary-off: 2 min. (fixed)
Sensor sensitivity: Automatic self-adapting sensor technology
Built-in filters: 0,5 mm mesh size
Aerator: Economic aerator, CASCADE (self-cleaning)
Flexible hoses: 350 mm
Angle valve connection: G 3/8
Click-plus: Protruding function key Click-plus (continuous-on, temporary-off)
Engineering standards: DIN EN 200; Noise class I; P-IX 9576 / IA; CE
