CONTI+ Power supply HDR-100-24N, 24 VDC, 4,2 A CONO582000
Power supply unit 24 V/DC / 4.2 A, for DIN rail mounting
For installation in sub-distribution boards.
For powering a maximum of 10 CONPRIMUS | CONVARIO or lino PRIMUS L40 showers or 1 CONCASH 2.0 coin-operated machine.
or
For supplying power to a maximum of 20 electronic showers, CONGENIAL FIT or CONBASE wall-mounted washbasin fittings, CONGENIAL series washbasin distributors and CONFLUSH flush units.
or
For supplying power to a maximum of 20 kits for thermal disinfection for mechanical showers.
Wiring must be carried out by a qualified electrician according to DIN VDE 105-100.
Connection voltage: 230 V/AC, 50/60 Hz
Output voltage: 24 V ± 1% DC
Output Power: 100.8 W
Output current: 0 - 4.2 A
Dimensions (WxHxD): 90 x 70 x 55 mm
Protection class: II
